• Rating：12VDC 50mA
• Travel：0.25mm
• Life：100,000~300,000 cycles
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：A=180gf B=260gf
• Operating Temperature：-30℃ ~80℃
• Height(ZTM-5)：15=1.5mm 17=1.7mm
20=2.0mm 43=4.3mm |
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Life | Operating Temperature | Height(ZTM-5) | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| RZTM-385 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTM-3307 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTM-3309 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTM-3312 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTM-325 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTMU-325 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTM-415 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTMF-5 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTMR-5 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTMS-5 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
| RZTMU-5 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 100,000~300,000 cycles | -30℃ ~80℃ | 15=1.5mm 17=1.7mm 20=2.0mm 43=4.3mm | 0.25mm | 暫無 |
